Interprosthetic Joint Motion in Bipolar Partial Hip Arthroplasty After One-Year Follow-up
Article Sidebar
Main Article Content
Abstract
Background. Partial hip arthroplasty is the treatment of choice for displaced proximal femoral fractures in the elderly. The bipolar prosthesis was developed to lessen the acetabular erosion encountered with the unipolar prosthesis. However, bipolar prostheses lose their motion between the inner or outer articulation (interprosthetic joint motion) after three months, rendering them biomechanically like unipolar prostheses. Meanwhile, other literature has shown that the interprosthetic joint is mobile radiographically up to one year after the surgery.
Objective. This study evaluated and quantified the interprosthetic joint motion (motion between the outer and inner articulations) of bipolar prostheses one year after partial hip arthroplasty for proximal femoral fractures in a tertiary hospital. We also investigated the effect of adding the hip measurement in adduction.
Methodology. This retrospective cohort study measured the motion of the outer and inner articulations of locally available bipolar prostheses and the interprosthetic joint movement using one-year postoperative radiographs of patients who underwent bipolar partial hip arthroplasty for femoral fractures in a tertiary hospital from 2019 to 2021. Immediate and one-year post-operative AP radiographs in neutral, maximum hip abduction, and maximum hip adduction were measured and compared. The interprosthetic joint motion was calculated from the difference in pelvic-head angles and pelvic-shaft angles.
Results. Twelve patients were included in the study. The interprosthetic joint in bipolar prosthesis was still mobile even after one year in 75% of patients (p = 0.0001). Adding hip adduction measurements resulted in a significantly higher mean of 74.69 degrees as compared to only 34.67 degrees (p = 0.0006).
Conclusion. Most patients retained a mobile interprosthetic joint at one year post-op. Hip adduction radiographs gave additional information on the total interprosthetic joint motion. At both time points studied, the inner head articulation contributed more to the interprosthetic joint motion. All five locally available implant systems used showed good motion after one year.
Article Details
This work is licensed under a Creative Commons Attribution 4.0 International License.
References
Bateman JE. Single-assembly total hip prosthesis—preliminary report. Orthop Digest. 1974;2:15–22.
Hedbeck CJ, Blomfeldt R, Lapidus G, Törnkvist H, Ponzer S, Tidermark J. Unipolar hemiarthroplasty versus bipolar hemiarthroplasty in the most elderly patients with displaced femoral neck fractures: a randomized, controlled trial. Int Orthop. 2011:35(11):1703-11. https://pubmed.ncbi.nlm.nih.gov/21301830 https://www.ncbi.nlm.nih.gov/pmc/articles/PMC3193971 https://doi.org/10.1007/s00264-011-1213-y
Ng ZD, Krishna L. Cemented versus cementless hemiarthroplasty for femoral neck fractures in the elderly. J Orthop Surg (Hong Kong) 2014;22(2):186–9. https://pubmed.ncbi.nlm.nih.gov/25163952 https://doi.org/10.1177/230949901402200214
Iamthanaporn K, Chareancholvanich K, Pornrattanamaneewong C. Reasons for revision of failed hemiarthroplasty: Are there any differences between unipolar and bipolar? Eur J Orthop Surg Traumatol. 2018;28(6):1117-23. https://pubmed.ncbi.nlm.nih.gov/29549451 https://doi.org/10.1007/s00590-018-2176-0
Rai AK, Singh S, Kumaraswamy V, Khare G, Yadav V, Agarwal R. Bicentric bipolar hip prosthesis: A radiological study of movement at the interprosthetic joint. Indian J Orthop. 2011;45(6):508-13. https://pubmed.ncbi.nlm.nih.gov/22144743 https://www.ncbi.nlm.nih.gov/pmc/articles/PMC3227354 https://doi.org/10.4103/0019-5413.87120
Bochner RM, Pellicci PM, Lyden JP. Bipolar hemiarthroplasty for fracture of the femoral neck. Clinical review with special emphasis on prosthetic motion. J Bone Joint Surg Am. 1988;70(7):1001-10. https://pubmed.ncbi.nlm.nih.gov/3403568.
Long JW, Knight W. Bateman UPF prosthesis in fractures of the femoral neck. Clin Orthop Relat Res. 1980;(152):198-201. https://pubmed.ncbi.nlm.nih.gov/7438604.
Cornell CN, Levine D, O'Doherty J, Lyden J. Unipolar versus bipolar hemiarthroplasty for the treatment of femoral neck fractures in the elderly. Clin Orthop Relat Res. 1998;(348):67-71. https://pubmed.ncbi.nlm.nih.gov/9553535.
Ong BC, Maurer SG, Aharonoff GB, Zuckerman JD, Koval KJ. Unipolar versus bipolar hemiarthroplasty: functional outcome after femoral neck fracture at a minimum of thirty-six months of follow-up. J Orthop Trauma. 2002;16(5):317-22. https://pubmed.ncbi.nlm.nih.gov/11972074 https://doi.org/10.1097/00005131-200205000-00005
Rogmark C, Leonardsson O. Hip arthroplasty for the treatment of displaced fractures of the femoral neck in elderly patients. Bone Joint J. 2016;98-B(3):291-7. https://pubmed.ncbi.nlm.nih.gov/26920951 https://doi.org/10.1302/0301-620X.98B3.36515
Gebhard JS, Amstutz HC, Zinar DM, Dorey FJ. A comparison of total hip arthroplasty and hemiarthroplasty for treatment of acute fracture of the femoral neck. Clin Orthop Relat Res. 1992;(282):123-31. https://pubmed.ncbi.nlm.nih.gov/1516303.
Wang F, Zhang H, Zhang Z, Ma C, Feng X. Comparison of bipolar hemiarthroplasty and total hip arthroplasty for displaced femoral neck fractures in the healthy elderly: a meta-analysis. BMC Musculoskelet Disord. 2015;16:229. https://pubmed.ncbi.nlm.nih.gov/26316274 https://www.ncbi.nlm.nih.gov/pmc/articles/PMC4552391 https://doi.org/10.1186/s12891-015-0696-x
Lestrange NR. Bipolar arthroplasty for 496 hip fractures. Clin Orthop Relat Res. 1990;(251):7-19. https://pubmed.ncbi.nlm.nih.gov/2403876.
LaBelle LW, Colwill JC, Swanson AB. Bateman bipolar hip arthroplasty for femoral neck fractures. A five- to ten-year follow-up study. Clin Orthop Relat Res. 1990;(251):20-5. https://pubmed.ncbi.nlm.nih.gov/2295175.
Wetherell RG, Hinves BL. The Hastings bipolar hemiarthroplasty for subcapital fractures of the femoral neck. A 10-year prospective study. J Bone Joint Surg Br. 1990;72(5):788-93. https://pubmed.ncbi.nlm.nih.gov/2211757 https://doi.org/10.1302/0301-620X.72B5.2211757
Kanto K, Sihvonen R, Eskelinen A, Laitinen M. Uni- and bipolar hemiarthroplasty with a modern cemented femoral component provides elderly patients with displaced femoral neck fractures with equal functional outcome and survivorship at medium-term follow-up. Arch Orthop Trauma Surg. 2014;134(9):1251-9. https://pubmed.ncbi.nlm.nih.gov/25055754 https://doi.org/10.1007/s00402-014-2053-1
Parker MJ, Gurusamy KS, Azegami S. Arthroplasties (with and without bone cement) for proximal femoral fractures in adults. Cochrane Database Syst Rev. 2010;(6):CD001706. https://pubmed.ncbi.nlm.nih.gov/20556753 https://doi.org/10.1002/14651858.CD001706.pub4
Verberne GH. A femoral head prosthesis with a built-in joint. A radiological study of the movements of the two components. J Bone Joint Surg Br. 1983;65(5):544-7. https://pubmed.ncbi.nlm.nih.gov/6643555 https://doi.org/10.1302/0301-620X.65B5.6643555
Eiskjaer S, Boll K, Gelineck J. Component motion in bipolar cemented hemiarthroplasty. J Orthop Trauma. 1989;3(4):313-6. https://pubmed.ncbi.nlm.nih.gov/2600699 https://doi.org/10.1097/00005131-198912000-00010
Phillips TW. The Bateman bipolar femoral head replacement. A fluoroscopic study of movement over a four-year period. J Bone Joint Surg Br. 1987;69(5):761-4. https://pubmed.ncbi.nlm.nih.gov/3680337 https://doi.org/10.1302/0301-620X.69B5.3680337
Brueton RN, Craig JS, Hinves BL, Heatley FW. Effect of femoral component head size on movement of the two-component hemi-arthroplasty. Injury. 1993;24(4):231-5. https://pubmed.ncbi.nlm.nih.gov/8325679 https://doi.org/10.1016/0020-1383(93)90175-6
Hodgkinson JP, Meadows TH, Davies DR, Hargadon EJ. A radiological assessment of interprosthetic movement in the Charnley-Hastings hemiarthroplasty. Injury. 1988;19(1):18-20. https://pubmed.ncbi.nlm.nih.gov/3169971 https://doi.org/10.1016/0020-1383(88)90167-2
Brady AP. Error and discrepancy in radiology: inevitable or avoidable? Insights Imaging. 2017;8(1):171-82. https://pubmed.ncbi.nlm.nih.gov/27928712 https://www.ncbi.nlm.nih.gov/pmc/articles/PMC5265198 https://doi.org/10.1007/s13244-016-0534-1
